This Style All-Road 56cm frame is a rocket ship that is ready to take on any event or club ride with ease!
The frame is configured with internal brake/shift cables routed through the downtube on the front half of the frame and internal through the chainstays for a clean overall appearance.
Frame Breakdown:
Custom Node Gravel 56cm (See Drawing for Measurements)
44mm Straight Headtube
31.6mm Seat tube
T47 Bottom Bracket
142 x 12mm Dropouts w/Flat Mount Disc (Not UDH Compatible)
Internal Shift Cable Routing Front & Internal Rear
Mechanical or Wireless Compatible Shifting
700 × 40mm Tire Clearance
Satin Finish w/Brushed Logos
