• Tubing: Hand Picked Size Specific Custom 3/2.5 CWSR Titanium

• Head Badge: Sanitas Custom

• Bottle Mount Options: Down Tube (upper and lower) and Seat Tube Locations.

• Bag Mount Options: Top Tube

• Rack & Fender Mounts: Optional & Avaiable Upon Request

• Finish:  Ceramic Bead Blast with Brushed Logo or Anodization at Upcharge.

• Production:  Hand Made One by One in Durango, Colorado

• Custom Sizing: No Additional Charge

• Lead time From Time of Order: 10 to 12 weeks

• Fork: Enve Adventure or Whisky No 9 (Order Separately)

• Headset: White Industries ( Order Separately)

• Frame Weight: 3.0 to 3.5 lbs. depending on Sizing.

• Build Kit Options: Contact us direction to put together your unique build kit

• Groupsets:  SRAM, Shimano, or Rotor

• Cockpits:  Sanitas Titanium or Ritchey

• Wheels: Rolf Prima, Boyd, Zipp or Enve

• Tire: Schwalbe, Continental, Maxxis or Pirelli

• Saddles:  Selle Italia or WTB

• Recommended Use: Bikepacking / Adventure

• Custom Sizing: No Additional Upcharge

• Tire Width: 29, 27.5 or 26 x 3.0”

• Headtube: 44mm Straight Taper

• Bottom Bracket: T47 - 73mm

• Rear Hub Spacing: 148 x 12mm Boost

• Cable Routing: External or Internal

• Front Derailleur: 34.9m Clamp-On

• Brake: Flat or Post Mount Disc.

• Seatpost Diameter: 31.6 mm

• Seat Collar: Sanitas Titanium or Wolf Tooth Alloy

• Manufacturer Warranty: Lifetime

Each Vacuole is a custom fabrication handmade to order to your specific fitment needs.

Click to view fit sheet
